Phasic is most easily installed using either Pixi, Conda or Pip:
Add conda channel:
pixi workspace channel add munch-groupInstall without jax:
pixi install phasicFor gradient-based inference using SVGD, the jax library is also required:
pixi install phasic jaxInstall without jax:
conda install -c munch-group -c conda-forge phasicFor gradient-based inference using SVGD, the jax library is also required:
conda install -c munch-group -c conda-forge phasic jaxInstall without jax:
pip install phasicFor gradient-based inference using SVGD, the jax library is also required:
pip install phasic[jax]Phase-type distributions describe waiting time until the end of a Markov jump process - systems that move through multiple states on its the way to a final (absorbing) state. A Markov jump process is a system that exists in one of several states at any moment and randomly jumps between states at rates determined only by the present state.
The simplest possible model has a single state in where it stays with process—you start, wait some random amount of time, then finish.
Below we construct a model of a Markov jump process with just a single state. The model is formulated as a graph created using the Python API. The Graph object automatically includes a starting vertex, which we retrieve, and then we create an absorbing state (the end point) using find_or_create_vertex(). Finally, we connect these states with an edge whose weight represents the transition rate:
from phasic import Graph
# Create a graph with 1-dimensional states
graph = Graph(1)
# Get the builtin starting state
start = graph.starting_vertex()
# this connects to a waiting state
vertex = graph.find_or_create_vertex([1])
start.add_edge(vertex, 1.0)
# which, in turn, connect to an absorbing state with a rate of 2
absorbing_vertex = graph.find_or_create_vertex([2])
vertex.add_edge(absorbing_vertex, 2.0)
graph.plot()
This models an exponential distribution with rate 2.0. Once we’ve constructed the graph, we can compute moments directly. The expected waiting time is 1/rate = 0.5, which we verify by calling expectation() on the graph:
graph.expectation()0.5Once you’ve built a model, you can compute probability distributions. Below we demonstrate how to evaluate both the probability density function (PDF) and cumulative distribution function (CDF) at specific time points. The pdf() method returns the probability density at a given time, while cdf() returns the probability that the waiting time is less than or equal to that time:
import numpy as np
# Evaluate PDF (probability density function)
time = 1.0
density = graph.pdf(time)
print(f"PDF at t=1: {density}")
# Evaluate CDF (cumulative distribution)
prob = graph.cdf(time)
print(f"P(T ≤ 1) = {prob}")
# Or evaluate at multiple times
times = np.linspace(0, 5, 100)
pdf_values = np.array([graph.pdf(t) for t in times])
cdf_values = np.array([graph.cdf(t) for t in times])PDF at t=1: 0.0
P(T ≤ 1) = 2.0Beyond computing distributions analytically, you can also draw random samples from the distribution. This is useful for Monte Carlo simulation or for validating your model by comparing sample statistics to theoretical moments:
# Sample 1000 waiting times
samples = graph.sample(1000)
print(samples[:10]) # Show first 10 samples
print(f"Sample mean: {np.mean(samples):.3f}")[0. 0. 0. 0. 0. 0. 0. 0. 0. 0.]
Sample mean: 0.000Real processes often have multiple stages. In the example below, we construct a three-stage process known as an Erlang distribution. The process must pass through three consecutive states before reaching absorption. We create each state using find_or_create_vertex() with different state labels, then connect them sequentially using add_edge(). Each transition has the same rate (1.0), so the expected time in each stage is 1.0, and the total expected time is the sum across all stages:
graph = Graph(1)
# Create states: start (0) → stage1 → stage2 → end
start = graph.starting_vertex()
stage1 = graph.find_or_create_vertex([1])
stage2 = graph.find_or_create_vertex([2])
end = graph.find_or_create_vertex([3])
# Connect them with rates
start.add_edge(stage1, 1.0)
stage1.add_edge(stage2, 1.0)
stage2.add_edge(end, 1.0)
# Expected time is sum of stage times: 1/1 + 1/1 + 1/1 = 3
expectation = graph.expected_waiting_time()[0]
print(f"Expected time: {expectation}") # 3.0
graph.plot()Expected time: 2.0
Overriding theme from NOTEBOOK_THEME environment variable. <phasic._DeviceListFilter object at 0x1633a53d0>
Processes can also branch—from one state, you might go to different next states with different probabilities. Below we extend the previous examples to include branching. We create two alternative paths from the starting state: a fast path and a slow path. The process randomly chooses one path at the start. When multiple edges leave a state, the relative rates determine the branching probabilities (3.0/(3.0+1.0) = 75% for the fast path). We then call normalize() to convert all transition rates into proper probabilities, ensuring they sum to one at each state:
graph = Graph(1)
start = graph.starting_vertex()
# Two possible paths
fast_path = graph.find_or_create_vertex([1])
slow_path = graph.find_or_create_vertex([2])
end = graph.find_or_create_vertex([3])
# Branch at start (rates determine probabilities)
start.add_edge(fast_path, 3.0) # 75% probability
start.add_edge(slow_path, 1.0) # 25% probability
# After normalization, fast path completes quickly, slow path slowly
graph.normalize() # Convert rates to probabilities
fast_path.add_edge(end, 5.0)
slow_path.add_edge(end, 1.0)
graph.plot()Overriding theme from NOTEBOOK_THEME environment variable. <phasic._DeviceListFilter object at 0x1633a53d0>
Often you want to track not just when something happens, but how much accumulates along the way. Rewards let you associate values with states. In the example below, we construct a simple three-stage process and then assign different reward values to each state. These rewards might represent costs, accumulated mutations, or any other quantity that accrues over time. By passing the reward array to expected_waiting_time(), we compute the expected accumulated reward—the sum of rewards weighted by the time spent in each state:
graph = Graph(1)
start = graph.starting_vertex()
state1 = graph.find_or_create_vertex([1])
state2 = graph.find_or_create_vertex([2])
end = graph.find_or_create_vertex([3])
start.add_edge(state1, 1.0)
state1.add_edge(state2, 1.0)
state2.add_edge(end, 1.0)
# Assign rewards to each state
# For example: cost per unit time spent in each state
rewards = np.array([0.0, 2.0, 5.0, 0.0]) # One reward per vertex
# Expected accumulated reward (weighted waiting time)
expected_reward = graph.expected_waiting_time(rewards)[0]
print(f"Expected cost: {expected_reward}")
graph.plot()Expected cost: 7.0
Overriding theme from NOTEBOOK_THEME environment variable. <phasic._DeviceListFilter object at 0x1633a53d0>
This computes the expected value of the accumulated reward—essentially the weighted sum of time spent in each state. Rewards are fundamental for working with multivariate phase-type distributions where you track multiple quantities simultaneously.
For larger models, manually creating vertices becomes tedious. You can use a callback function to define transitions programmatically. In the example below, we demonstrate this with a simple coalescent model from population genetics. Instead of manually creating vertices and edges, we define a function build_transitions() that specifies what transitions are possible from any given state. The function receives a state (represented as a list of integers) and returns a list of possible transitions, each specified as a tuple of (next_state, rate).
When we pass this callback to Graph(), the library automatically explores the state space: it starts with an empty state, calls the function to find the next states, then recursively calls it for each new state discovered. This approach is particularly powerful for models where the state space structure is complex or depends on parameters:
def build_transitions(state):
"""Define transitions from a given state."""
transitions = []
n = state[0]
if n > 1:
# Coalescence rate: n choose 2
rate = n * (n - 1) / 2
transitions.append(([n - 1], rate))
return transitions
# Build graph automatically
graph = Graph(build_transitions, ipv=[([2], 1.0)] )
# Compute expected coalescence time
expectation = graph.expected_waiting_time()[0]
print(f"Expected coalescence time: {expectation}")
graph.plot()Expected coalescence time: 1.0
Overriding theme from NOTEBOOK_THEME environment variable. <phasic._DeviceListFilter object at 0x1633a53d0>
The library automatically builds the state space by repeatedly calling your function for each newly discovered state. This callback-based construction is the foundation for building large, complex models efficiently.
